A new software update (DCAG1-30) is now available for the EL-52800 Diagnostic Charge Battery Station (DCBS) (Fig. 8). The DCBS replaces the EL-50313 Midtronics GR8 Battery Tester/Charger and is available for order through GM Dealer Equipment.

Battery Reference Values To find your reference value, type the battery model number into the search box below and click GO. You can also select a battery manufacturer from the drop down menu below to see all of the models that have a confirmed reference value for a particular manufacturer. View and Download Midtronics PBT-200 instruction manual online. For testing 12-volt automotive starting batteries. PBT-200 test equipment pdf manual download.

Fig. 8

The software update includes:

• The latest available GM vehicle database, including 2021 model year vehicles
• Restoring the tester’s input current capacity from 40 amps to 80 amps, allowing for faster performance and, in many instances, reduced diagnostic time
• Additional language options for the DCBS’s printer

When dealerships receive the new DCBS unit, it is critical that the Optimus software, which is included with the DCBS, be downloaded. The Optimus website is used to store all the testing records (up to 65,000) that are performed at the dealership and enables dealerships to view past test records and retrieve warranty codes. Additionally, all DCBS software updates that are released to keep the DCBS operating with the latest vehicle information and product enhancements will only be delivered to the handheld diagnostic remote through the Optimus program.

Updating the Software

To complete the software update, connect the handheld remote to the PC using the USB cable. If this is the first time updating the device, go to the E-XTEQ website at www.e-xteq.com and select the Download option on the top menu bar. Once accessed, click Download Optimus and follow the prompts to install the updating Optimus software. If the device has been updated before, Optimus should already be on the PC. Open Optimus and follow the prompts to update the device.

Refer to the DCBS Software Installation Guide for more information. (Fig. 9)

Fig. 9

Electronic Battery Tester Midtronics

All DCBS units should be updated to the latest software version DCAG1-30 to ensure battery testing is being performed with the latest technology and information.

Midtronics Battery Tester Reference Values

For assistance with accessing the website, downloading the software or any questions about the DCBS, contact EXTEQ Customer Support Center at 1-877-453-3265.

Midtronics Battery Tester

– Thanks to Rob Kennedy
