• • EVEN MORE EFFICIENT
    The new generation BOGE S series has the most efficient airend ever employed by BOGE – the BOGE effilence.
  • EVEN QUIETER!
    As well as the innovative BOGE effilence airend, the new designed fan makes the BOGE S-3 series quieter than ever. Its speed has been halved resulting in reduced noise levels – while the cooling air has been improved at the same time.
  • PROVEN CONTROL
    The compressor control in the standard version uses a familiar and intuitive FOCUS control which provides numerous monitoring and control features that allows connection to master control system.
  • PROVEN DESIGN
    Irrespective of the modification incorporated, the proven design of the S series has still been retained: providing the advantages of the efficient cooling air circulation and the effective optimized oil separation system.

  Reliable and efficient even with large compressed air demands: the proven 60 HP S series. The intelligent design ensures maximum efficiency and maximum safety.

  Product

  Screw compressor, oil lubricated

  Advantages

  • heat recovery can be integrated
  • extremely quiet
  • focus control 2.0
  • maximum efficiency
  • frequency controlled cooling fan

• BOGE	Max. Pressure	Effective Delivery Volume 60 Hz	Motor Power	Dimensions W × D × H	Weight
  Type	psig	m3/mincfm	hp	inch	lbs
  S 40-3 N	100	5.444 192.2	40	64 x 39 x 57	1857
  S 40-3 N	115	5.210 184.0	40	64 x 39 x 57	1857
  S 40-3 N	150	4.770 168.4	40	64 x 39 x 57	1857
  S 40-3 N	190	3.980 140.5	40	64 x 39 x 57	1857
  S 50-3 N	100	6.810 240.3	50	64 x 39 x 57	1859
  S 50-3 N	115	6.360 224.6	50	64 x 39 x 57	1859
  S 50-3 N	150	5.650 199.4	50	64 x 39 x 57	1859
  S 50-3 N	190	4.750 167.7	50	64 x 39 x 57	1859
  S 60-3 N	100	7.620 269.1	60	64 x 39 x 57	2192
  S 60-3 N	115	7.300 257.8	60	64 x 39 x 57	2192
  S 60-3 N	150	6.420 226.5	60	64 x 39 x 57	2192
  S 60-3 N	190	5.230 184.6	60	64 x 39 x 57	2192

• • BROCHURE S-3 SERIES

    PDF, 5 MB

  • TECH DATA S-3 SERIES

    PDF, 1 MB

Boge Compressor Repair Manual Pdf

• • MAXIMUM EFFICIENCY
    The BOGE C series up to 22 kW is characterised by its industry leading specific power ratios. You rarely come across such compact screw compressor efficiency.
  • EXTREMELY QUIET
    All C series compressors feature very low sound pressure levels.
  • CONTROL
    The compressor is controlled by the base control system with LC display and pressure sensor technology. focus control 2.0 system is available as an option.

  The compact compressors of the C Series work reliably and safely when large amounts of compressed air are required. Thanks to the integrated design, the connection distances are short, meaning pressure losses are minimal. The compressors need exceptionally low energy and still get full power.

  Product

  Compact class screw compressor, oil lubricated

  Advantages

  • heat recovery can be integrated
  • compact design
  • extremely quiet
  • maximum efficiency

  Compressed air accessories for this product

  Other construction variants

• BOGE	Max. Pressure	Effective Delivery Volume 50 Hz	Motor Power	Dimensions W × D × H	Weight
  Type	barpsig	m3/mincfm	kWhp	mm	kg
  C 15	8 115	1.740 61.4	11 15	722 x 1060 x 1740	398
  C 15	10 150	1.530 54.0	11 15	722 x 1060 x 1740	398
  C 15	13 190	1.330 47.0	11 15	722 x 1060 x 1740	398

  BOGE	Pressure	Effective Delivery Volume 60 Hz	Motor Power	Dimensions W × H × D	Weight
  Type	barpsig	m3/mincfm	kWhp	mm	kg
  C 15	8 115	1.740 61.4	11 15	722 x 1060 x 1740	398
  C 15	10 150	1.530 54.0	11 15	722 x 1060 x 1740	398
  C 15	13 190	1.330 47.0	11 15	722 x 1060 x 1740	398
